1200.2 EVO 5 – 2 OHMS
Power @ 1Ω: 2 X 600W RMS
Power @ 2Ω: 2 X 396W RMS
Power @ 4Ω: 2 X 262W RMS
Bridge Power @ 2Ω: 1 X 1200W RMS
Bridge Power @ 4Ω: 1 X 792W RMS
1200.2 EVO 5 – 4 OHMS
Power @ 1Ω: N/A
Power @ 2Ω: 2 X 600W RMS
Power @ 4Ω: 2 X 396W RMS
Bridge Power @ 2Ω: N/A
Bridge Power @ 4Ω: 1 X 1200W RMS
Operating Voltage:
8V – 16V
Current Draw (Max)
2Ω: 57A
4Ω: 58A
Current Draw (Music)
2Ω: 115A
4Ω: 116A
Recommended Fuse (Music):
60A
Total Efficiency:
2Ω: 83%
4Ω: 82%
Damping Factor:
200
Frequency Response (-3dB):
5Hz – 22kHz
SNR:
91dB
Crossover
HPF: 80Hz
LPF: 80Hz
Width:
5.4 in / 13,6 cm
Length:
6.7 in / 17 cm
Height:
2.2 in / 5,5 cm
Weight:
1,14 Kg
