Composition
L200P HIGH POWER WOOFER
200 mm (8″) woofer
Max power 200 W – Nominal power 100 W
Frequency response 40 Hz – 8 kHz
Sensitivity 94.4 dB – Impedance 2 Ω
Machined cast aluminium basket – Epoxy resin and glass fiber cone – Butyl rubber surround – Long life “Conex” damper – 38 mm (1.5’’) voice coil with kapton former – 110 mm x 20 mm (4.3’’ x 0.8’’) motor assembly – Thick magnetic circuit 5 mm
LT25 HIGH QUALITY TWEETER
25 mm (1’’) high quality soft dome tweeter
Max power 100 W – Nominal power 15 W
Frequency response 2.5 kHz – 25 kHz
Sensitivity 91.6 dB – Impedance 3 Ω
High efficiency N38 neodymium motor
BFT02 HIGH QUALITY CROSSOVER
High pass 12 dB/octave crossovers
Adjustable tweeter level to +3 dB, 0 dB or attenuated -3 dB
Supplied Accessories:
Mounting screws
Tweeters accessories – Angled support included
User manual
